Salitek 60-Series

SAL-MPDP60C4

Infinitely Expandable | Multi Display MPDP

Salitek’s bezel-less design features a total seam size of only 1.8mm reproducing bigger, unobstructed images. Salitek’s cutting edge Multi Vision Display is an innovative video wall solution which can be configured to any size with no resolution limitation.

“Near Seamless Design Infinitely Expandable Multi-Vision”

  • Virtually Seamless Design

  • Infinitely Expandable Display

  • Image Sticking Compensation (ISC)

  • Superior Picture Quality & Performance

Virtually Seamless Screen

The seam size of one side is only 0.9mm

sal60VIRTUALLY SEAMLESS SCREEN.jpg

Faster response

Multi Vision Displays are engineered with self-illuminating pixels and fast response time of 0.001ms with 600h Subfield Driving technology.


ACCURATE COLOR

Multi Vision Displays reproduce natural and accurate colors found on a reference monitor or a standard color map.


WIDE VIEWING ANGLE

Realistic colors are combined with a wide viewing angle to preserve picture clarity. The wide view-ing angle provides a superior viewable image from almost any direction.


Superior White Uniformity

Inherent edge to edge uniformity


Image Sticking Compensation

Burn-in management system


Specifications

Diagonal 60” (16:9)
Resolution 1,365(H) x 768(V)
Peak Brightness 700cd/m²
Contrast Ratio Typical 1,000,000:1
Display Area 1,318.6(H) x 741.9(V) ± 0.5mm
Filter Type AG Film Filter
Seam Size 0.9mm
Dimensions [W x H x D] 52.05 x 29.35 x 2.17 Inches
Weight 72.75lbs
Operating Temperature 0°C - 40°C
Expected Life-Time 100,000 Hours
Expected Life-Time 100,000 Hours
Power | Input Voltage AC 100-240V (50/60hz)
Connectivity | Input HDMI, Display Port, DVI, RGB, RS232c, IR, USB(SVc)
Connectivity | Output DVI, RS232C
